| Model | 단위 | LS - 150C |
|---|---|---|
| Sash height (FH) | mm | 840 to 2690 |
| Sash width (FB) | mm | 570 to 3200 |
| Sash weight | Kg | max. 150 |
| Backset | mm | 27.5 |
| Sash thickness | mm | 56, 66 or 68 |
| Handle position | ||
| Sash height (FH) 1190 to 1590 | 410 | |
| Sash height (FH) 1751 to 3090 | 1010 | |
| Gear size | mm | 170, 190, 200, 230, 260 or 300 |
| PROFILE MATERIAL | P.V.C | ALUMINUM | WOOD |
|---|---|---|---|
| WIDTH(L)22mm , HEIGHT(H)42.5mm | LS-150C | LS-150CA | LS-150CW |
